Description
DM Pack’s FLO is an advanced automatic L-sealer packaging machine, designed for high-quality sealing, film savings, and maximum flexibility in product packaging. The FLO series uses an innovative vertical sealing bar system instead of the traditional scissors system, ensuring uniform pressure across the entire film and excellent final packaging quality.
The thin vertical bar, just 10 mm thick, significantly reduces film consumption, creating tight and elegant packaging with minimal excess material around the product. The machine supports operation with polyolefin (POF) and polyethylene (PE) films, as well as the use of flat film via an external center-folding unit.
The FLO can operate either as a standalone unit or in a COMBO version with a built-in shrink tunnel for space savings and higher efficiency. It is also available with conveyor systems, pushers, loaders, stackers, and various feeding systems, allowing it to be fully customized to the needs of any production line.
The Siemens touchscreen display, motorized format adjustment, and easy access to the reel unwinder and waste collector via a sliding door enable quick product changeovers and easy maintenance. The FLO is the ideal solution for the food, cosmetics, printing, plastics, and general manufacturing industries that require reliable, high-quality heat-shrink packaging.
| Μοντέλο | 530 / 530 T 530 CS / 530 CST | 560 / 560 T 560 CS / 560 CST | 790 CS |
|---|---|---|---|
| Διαστάσεις συγκόλλησης | 450 x 600 mm | 500 x 650 mm | 750 x 950 mm |
| Μέγιστο πλάτος προϊόντος | 350 mm | 420 mm | 700 mm |
| Μέγιστο μήκος προϊόντος | 550 mm | 650 mm | 950 mm |
| Μέγιστο ύψος προϊόντος | 150 / 150 mm 240 / 170 mm | 200 / 170 mm 240 / 200 mm | 240 mm optional up to 400 mm |
| Πλάτος φιλμ | 550 mm | 650 mm | 950 mm |
| Διάμετρος ρολού | 350 mm | 350 mm | 350 mm |
| Ηλεκτρική τροφοδοσία | 400V 50/60Hz 3PH + N + earth (άλλες τάσεις διαθέσιμες κατόπιν ζήτησης) | 400V 50/60Hz 3PH + N + earth (άλλες τάσεις διαθέσιμες κατόπιν ζήτησης) | 400V 50/60Hz 3PH + N + earth (άλλες τάσεις διαθέσιμες κατόπιν ζήτησης) |
| Πεπιεσμένος αέρας | 6 bar constant | 6 bar constant | 6 bar constant |
| Βασικό χρώμα | RAL 9007 | RAL 9007 | RAL 9007 |
| Ύψος εργασίας | 900 +/- 50 mm | 900 +/- 50 mm | 900 +/- 50 mm |
CS VERSION: έκδοση με motorized center seal, ρυθμιζόμενο καθ’ ύψος
