SPEED FORMER 50 SB Automatic Box Forming & Taping Machine

The SPEED FORMER 50 SB is an automatic American-style carton forming machine, which automatically folds and closes the four bottom flaps and seals the bottom with self-adhesive tape.

The forming process is achieved through fully synchronized movements, ensuring excellent squaring and stability of the box. The machine features a suction system with suction cups and a Venturi, which picks up the box from the side magazine and holds it in place during opening.

All settings are easily adjusted using handwheels, while operation is controlled by a Siemens PLC with a 7.2-inch color touchscreen, making the machine ideal for automated production lines that do not require a constant operator presence.

Key Features & Equipment

  • Fully automatic lower flap configuration
  • Bottom Tape-Applying Head (Standard)
  • Suction system with suction cups and a Venturi
  • Pneumatic operating system
  • Manual adjustment for changing dimensions
  • 7.2-inch color touchscreen
  • Control via Siemens PLC
  • Option for right- or left-hand gearbox output
  • Robust industrial construction
  • Stainless steel (SS) version available
  • Can be equipped with a motorized magazine up to 1,700 mm

Advantages

  • Fully automated forming and closing
  • High speed of up to 12 boxes per minute
  • Consistent quality in case forming
  • Reduced need for an operator
  • Easy resizing
  • Reliable operation during continuous use
  • Ideal for lines with uniformly spaced crates

Additional available models: SPEED FORMER 50 SB XL, SPEED FORMER 50 SB SS (Stainless Steel Version).
